mabe MMT09CABWCCC8 User Manual

50
2
1
3
4
Inlet Air purifying filter
(inside)
Inlet grille
Outlet
Horizontal louvers
(up and down airflow)
Vertical louvers
(left and right airflow)
Display
Emergency
switch
display board
display board A
5
6
2
3
4
1
1. Signal receiver hole.
2. Ambient temp. display. When receiving the remote control signal,
display the set temperature.
3. COOL display
4. HEAT display
5. HEALTH display
6. DRY display
outdoor unit
1. Outlet
2. Inlet
3. Connecting piping and electrical wiring
4. Drain hose

mabe MMT09CABWCCC8 Specifications

General

Brand	mabe
Model	MMT09CABWCCC8
Category	Air Conditioner
Language	English
