Removal Procedure
2 Domestic Air Conditioner
stnioPerudecorPpetS
2
3
4
Hold the front panel by
the tabs on the both
sides and lift it until it
stops with a click.
Loosen the screw and lift
up the casing cover
Loosen the screw and
lift up the control box
cover
Pull the wires out of the
control box and then
release the pivots on
both sides of the unit
to remove the front
panel.
