Changing the knives
• Put the main switch of the machine to OFF position.
• Pull the power supply plug from the socket.
• Block the cutter block guard in the lifted position.
• Release and remove the four knife clamping screws.
• Lift the knives and knife support from the cutter block.
• Remove the chips and any resin from the cutter block and knife support.
• Place new knives into the cutter block and x them with the rectangle
slots in both screw heads. (With these two screws, height-adjustment of
the knife is done.)
• Place the knife support onto the knife.
• Slightly tighten the four clamping bolts.
• Repeat these actions for the second knife.
• Then adjust the planer/thicknesser knives exactly with the output table.
Use a ruler that you put onto the output table.
• By the two set screws, the knife can be adjusted for height.
• By turning the cutter block and using the ruler, you can see the height
adjustment.
• The knife is exactly set, when the ruler is moved by the knives not hig-
her than 3 mm.
• After a successful knife setting, all clamping screws must be tightened
(8.4 N/m).
PLEASE MIND!!!
• Sharp planer/thicknesser knives guarantee a clean planing
surface and put less stress on the motor.
• After three grinding actions, a maximum material removal of
3 x 0.05 mm may not be exceeded.
• The planer/thicknesser blades used on this machine are not
suitable for rebating and dovetailing.
• Finally lower the cutter block guard again onto the table.
Cover the cutter block and block it with the star grip screw.
In more detail...
Operation
Transport
For transport, the machine may only be lifted on the base. Never lift it on the
guards, the setting handles or the planer/thicknesser table.
Before transporting, pull the power supply plug.
During transport, the cutter block guard must be set in the lowest position.
