FIG. 6 CONTROLS, INPUTS AND OUTPUTS
Channel 1 and 2: (1) Low-level input
(3) Input level control
(4) Selector high-pass filter on/off (HPF / FULL)
(5) High-pass crossover frequency adjustment
(6) Selector switch for the high-pass filter frequency range: 15 – 300 Hz or 300 – 6000 Hz
Channel 3 and 4: (2) Low-level input
(7) Input level control
(8) Selector low-pass filter off (FULL)
(9) Low-pass crossover frequency adjustment
(10) Selector switch for the low-pass filter frequency range: 50 – 600 Hz or 500 – 6000 Hzz
(11) Selector high-pass filter on/off (FULL / HPF)
(12) High-pass crossover frequency adjustment
Channel 5: (13) Low-level input
(14) Input level control
(15) Channel mode selector: internal/external (INT/EXT)
(16) Bass booster control
(17) Selector high-pass filter on/off (FULL / HPF)
(18) Cross-over frequency control for the subsonic filter
(19) Low-pass crossover frequency adjustment
(20) Phase regulator
(21) "On"/"off" switch for the remote control
(22) Connection for volume remote control
