71
Chassis
• 2.0 DIN (Import / ISO-DIN Mountable)
• Fixed Front Panel
Personal Color Adjustment (Color illustrations / background)
Extended graphical user interface adjustment with:
• 5 menu colors: green / red / orange / blue / purple (to set the background color on the LCD)
• 11 RGB light settings (keyboard / background illumination):
blue / green / white / yellow / purple / red / aqua blue / sky blue / 3 x user-dened
Wallpaper Selection:
• 5 Selectable Wallpaper Backgrounds / User Up-loadable Wallpaper
General
• Front 3.5 mm A/V input
• Front USB 2.0 input with 2.1 A charge current
• Rear auxiliary audio/video input (Composite)
• Video input for rear view camera (normal and opposite hand)
• 5 line audio outputs: 2x front, 2x rear and subwoofer (4 V RMS)
• Video output for TFT monitor
• SWC (Steering Wheel Control) connection via optionally available adapter (compatible with
Dietz UNICO DUAL PLUS (art. no. 66040) with cable (art. no. 66405), PAC (Pacic Accessory
Corporation) SWI-PS with Metra ASWC interface prole)
• 10-Band tone control with 6 preset and 1 user-dened EQ curves
• Sub X-over frequencies 80 / 120 / 160 Hz
• Programmable volume control for each audio source
• Calibration mode for touch screen
• Power supply: 11 to 16 VDC, negative ground
• Switch output for active antenna (blue): 500 mA max, overcurrent protection
• Operating temperature: 0°C to 65°C
• Fuse 15A mini ATO
• DIN chassis dimensions: 178 x 178 x 100 mm (7” x 7” x 4”)
• Front Panel USB/MicroSD card - Playback Music / Video Files via Portable Hard Drives / USB
sticks.
• HDMI / MHL Connectivity - See and control smartphone apps on the larger TFT screen.
*Some apps may not be supported.
• Push to Talk function (voice control) for Android / iPhone mobiles
