16 Input source for SD card reader: For playback of MP3 music.
17 Volume knob: Adjusts the volume. The volume is shown on the display (3). (VOL 00 - VOL 40/
max).
18 Light: Press the Light button to select the lighting effects (CLEIO, PEACE, POWER, CUSTOM and
Off). In addition, the intensity of the display can also be adjusted between setting 1 and 4 by
turning the button.
TECHNICAL SPECIFICATIONS
Phone Connectivity
Wireless Bluetooth® 2.1 with EDR (Enhanced Data Rate)
Operating frequency: 2402-2480 MHz
Maximum power transmitted acc. EN62479: 2.85 dBm
FM Tuner
RDS PLL Tuner (87.5 – 108 MHz)
FM aerial antenna (75 ohms)
Loudspeakers
2 x 50.8 mm (2“) tweeter, 2 x 165 mm (6.5“) woofer
Miscellaneous
Total power output 400 watts
Connections 2x USB input: MP3 playback
SD card reader for MP3 playback
AUX input (Line In): 3.5 mm jack
Mains voltage 100 – 240 V AC/50 – 60 Hz, built-in linear power mains adapter
Electricity consumption 200 W
Standby: < 0.5 W
Display/Settings 5 segment display (color: amber)
5x equalizer
Weight 13.9 kg
Dimensions (wxhxd) 326 x 953 x 340.5 mm
Subject to technical modications.
