MAC Audio MPX 4000 User Manual

13
GB
FIG. 6 USE AS AN AMPLIFIER FOR 4 SATELLITE LOUDSPEAKERS AND A SUBWOOFER USING AN
ADDITIONAL 1-CHANNEL AMPLIFIER (MPX MONO)
(1) To the car radio, front left output
(2) To the car radio, front right output
(3) To the car radio, rear left output
(4) To the car radio, rear right output
(5) Front left loudspeaker
(6) Front right loudspeaker
(7) Rear left loudspeaker
(8) Rear right loudspeaker
(9) Subwoofer
FIG. 7 OPERATING ELEMENTS AND IN/OUTPUTS
(1) Low-level inputs (channel 1/2, front)
(2) Low-level inputs (channel 3/4, rear)
(3) Input-level control channel 1/2
(4) Input-level control channel 3/4
(5) Bass-booster control (channel 1/2, front)
(6) Bass-booster control (channel 3/4, rear)
(7) FULL / LPF (low pass filter) / (HPF) high pass filter option switch for channel 1/2
(8) FULL / LPF (low pass filter) / (HPF) high pass filter option switch for channel 3/4
(9) Low-pass selector ON/OFF for channel 1/2
(10) Low-pass selector ON/OFF for channel 3/4
(11) Cross-over frequency control for the high pass (channel 1/2)
(12) Cross-over frequency control for the high pass (channel 3/4)
(13) Channel mode selector switch
(14) Low level outputs (Compound signal from CH1, CH2, CH3 and CH4)
130.com.ua
Autogood products Internet store “130”

MAC Audio MPX 4000 Specifications

General

Impedance	2 Ω
Frequency range	5 - 50000 Hz
RMS rated power	320 W
Audio output channels	4.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Channels quantity	4 channels
Power requirements	12 V DC
Equalizer	Yes
Product color	Black, Silver
Radio Data System (RDS)	No
Connectivity technology	Wired
Digital audio optical out	0

Weight and Dimensions

Weight	4650 g
