Z 4200
Stereo / Bridged
Max. output power (1 kHz sinus burst 2:8, B+=14.4V) 4 x 220 W / 2 x 750 W on 4 Ohm
Nominal output power (DIN 45 342, B+=14.4V) 4 x 110 W / 2 x 285 W on 4 Ohm
Max. output power (1 kHz sinus burst 2:8, B+=14.4V) 4 x 280 W on 2 Ohm
Nominal output power (DIN 45 342, B+=14.4V) 4 x 140 W on 2 Ohm
Loudspeaker impedance (stereo) 2 – 8 Ohm
Frequency response 5 – 50 000 Hz (-3 dB)
Total harmonic content (DIN 45 403) < 0.05% (1 kHz)
Stereo separation (IEC 581 ) > 60 dB (1 kHz)
Weighted noise distance (IEC A) > 100 dB
Input sensitivity LOW LEVEL INPUT 200 mV – 5 V
Input impedance LOW LEVEL INPUT 25kOhm
Low-pass filter 50 – 250 Hz, 12 dB per octave
High-pass filter 40 – 500 Hz, 12 dB per octave
Bass boost 0…12 dB at 45 Hz
Supply + 12V (9 – 15 V), minus to ground
Fuse 1 x 80 A Maxifuse
Sizes (W x H x D) 435 x 54 x 293 mm
Weight 5.9 kg
SUBJECT TO TECHNICAL CHANGE
2. FEATURES
• Complementary push-pull final stage
• Automatic switching on/off via car radio
• Infinitely adjustable high-pass filter 40 – 500 Hz
• Infinitely adjustable low-pass filter 50 – 250 Hz
• Infinitely variable bass equalisation
• Adjustable input sensitivity
• Bridgeable 4-/3-/2-channel mode
• Tri-mode
• Electronic protective circuit against short circuiting, DC offset and excess temperature
• Mute switch for suppressing switch-on crackle interference
• Capsulated loudspeaker and power-supply screw terminals
•
Low-level outputs (cinch jacks) for connecting additional amplifiers (channel 1 and 2 only)
• Status indicator (green LED) and overload indicator (red LED)
