Dear MAC AUDIO Customer,
The Z 4100 / Z 4200 car hi-fi power amplifier will enable you to satisfy your high demands on sound
reproduction in your car. With its impressive deep-bass power reserves, low harmonic content and neutral
reproduction, the Z 4100 / Z 4200 takes car hi-fi to new heights. The amplifier is characterized by low
operating current, rapid switching capabilities and excellent temperature stability. Experience and enjoy
how this high-tech machine perfectly reproduces magnificent sound.
Please read all of the owner's manual before installing and using the amplifier.
1. TECHNICAL DATA Z 4100
Stereo / Bridged
Max. output power (1 kHz sinus burst 2:8, B+=14.4V) 4 x 160 W / 2 x 500 W on 4 Ohm
Nominal output power (DIN 45 342, B+=14.4V) 4 x 80 W / 2 x 230 W on 4 Ohm
Max. output power (1 kHz sinus burst 2:8, B+=14.4V) 4 x 210 W on 2 Ohm
Nominal output power (DIN 45 342, B+=14.4V) 4 x 105 W on 2 Ohm
Loudspeaker impedance (stereo) 2 – 8 Ohm
Frequency response 5 – 50 000 Hz (-3 dB)
Total harmonic content (DIN 45 403) < 0.05% (1 kHz)
Stereo separation (IEC 581 ) > 60 dB (1 kHz)
Weighted noise distance (IEC A) > 100 dB
Input sensitivity LOW LEVEL INPUT 200 mV – 5 V
Input impedance LOW LEVEL INPUT 25kOhm
Low-pass filter 50 – 250 Hz, 12 dB per octave
High-pass filter 40 – 500 Hz, 12 dB per octave
Bass boost 0…12 dB at 45 Hz
Supply + 12V (9 – 15 V), minus to ground
Fuse 2 x 25 A
Sizes (W x H x D) 355 x 54 x 293 mm
Weight 4.75 kg
