FIG. 5 2-CHANNEL MODE
If the amplifier has to generate more power to operate two subwoofers, connect and set it as shown in
Fig. 5. The use of the low-pass filter used is described in Chapter 5.
(1) To the car radio, left output
(2) To the car radio, right output
(3) Subwoofer
(4) Subwoofer
FIG. 6 USE AS AN AMPLIFIER FOR FOUR SATELLITE LOUDSPEAKERS AND A SUBWOOFER
USING AN ADDITIONAL 2-CHANNEL AMPLIFIER (Z 2100 OR Z 2200)
(1) To the car radio, front left output
(2) To the car radio, front right output
(3) To the car radio, rear left output
(4) To the car radio, rear right output
(5) Front left loudspeaker
(6) Front right loudspeaker
(7) Rear left loudspeaker
(8) Rear right loudspeaker
(9) Subwoofer
FIG. 7 OPERATING ELEMENTS AND IN/OUTPUTS
(1) Low-level inputs (channel 1/2, front)
(2) Low-level inputs (channel 3/4, rear)
(3) Input-level control channel 1/2
(4) Input-level control channel 3/4
(5) Bass-boost control (channel 1/2, front)
(6) Bass-boost control (channel 3/3, rear)
(7) Cross-over frequency control for the low pass (channel 1/2)
(8) Cross-over frequency control for the low pass (channel 3/4)
(9) HPF (high-pass filter) / LPF (low-pass filter) / OFF option switch for channel 1/2
(10) HPF (high-pass filter) / LPF (low-pass filter) / OFF option switch for channel 3/4
(11) Cross-over frequency control for the high pass (channel 1/2)
(12) Cross-over frequency control for the high pass (channel 3/4)
(13) Channel mode selector switch
(14) Low level outputs (channel 1/2)
