Continuity Measurement
- Open circuit voltage: approx. 0.4V.
- Overload protection: 250V DC or AC rms.
Frequency (Through grade HZ/DUTY)
- Overload protection: 600V AC RMS.
- The input voltage range: ≥2V (input voltage will increase when the
frequency to be measured increases).
AC Current (Clamp head converter)
- Input impedance: 10MΩ.
- Input signal: 30A (720.P30).
400A/1500A (720.P1500).
Function Measuring range Resolution Accuracy
When built-in buzzer
sounds, the resistance
to be tested is less
than 40Ω.
Open circuit voltage:
about 0.4V.
Range Resolution Accuracy
60Hz 0.1Hz
± (1.0% of reading + 5 digits)600Hz 1Hz
3kHz 10Hz
Measuring Range Resolution Accuracy
3A 1A/100mV
± (2.5% of reading + 8 digits30A 1A/100mV
400A 1A/0.1mV
1500A 1A/0.1mV ± (3.0% of reading + 10 digits
