MAC TOOLS EM721 - RPM and Duty Cycle Specifications

800.MACTOOLS
73
Frequency (Hi-Sen Hz)
Range Resolution Accuracy
200Hz 0.01Hz ± (0.05% + 2)
2,000Hz 0.1Hz
20kHz 0.001kHz
200kHz 0.01kHz
Minimum Frequency: 0.5Hz
Sensitivity: 250mV
RPM IP
Range Resolution Accuracy
30 - 9,000RPM 1RPM ± (0.5% + 2)
7 selectable trigger levels and ± trigger slopes
RPM IG
Range Resolution Accuracy
60 - 12,000RPM 1RPM ± (0.5% + 2)
7 selectable trigger levels and ± trigger slopes
9 Selectable Cylinder Numbers: 1, 2, 3, 4, 5, 6, 8, 10, 12
Duty Cycle
Range Resolution Accuracy
0.0% - 99.9% 0.1% ± (0.2%/kHz + 1)
Pulse Width: > 2µs
7 selectable trigger levels and ± trigger slopes
