MAC 6000 Hydronic Heater
Riello Burner
2106 East Indiana Ave., Bismarck, ND 58504 U.S.A. • www.macheaters.com • +1-800-272-4604
2453
10
GB
BURNER SET-UP CHART
NON-RETROFIT APPLICATIONS
If this burner is being installed in a packaged unit (ie. burner comes with a boiler or furnace), follow the
installation and set-up instructions supplied with the heating unit, as settings will differ from those shown
in this manual.
NOZZLES RECCOMANDED:
Monarch R-PLP, Delavan W-B, Danfoss S-B, Steinen SS-S, Hago P.
NOTE:
A 45° degree nozzle is sugg ested, however, a 60° degree nozzle may be used in cases where the flame is
unstable at light-off when operated at low ambient temperatures.
1 2 3 4 5
Actual
Firing
Rate ± 5%
Nozzle
Size
Pump
Pressure
Turbulator
Setting
Air Damper
Setting
GPH Kg/h GPH PSI bar Low Fire Main Flame
3.50 11.3 2.50 x 45°/60° 190 13.0 0.0 2.3 2.8
4.00 12.9 3.00 x 45°/60° 178 12.0 1.0 2.5 3.2
4.65 15.0 3.50 x 45°/60° 178 12.0 2.0 2.8 3.7
5.30 17.1 4.00 x 45°/60° 178 12.0 3.0 3.2 4.5
6.00 19.4 4.50 x 45°/60° 178 12.0 4.0 3.5 5.0
6.40 20.7 5.00 x 45°/60° 165 11.4 5.0 3.8 6.0
