MAC 6000 Hydronic Heater
Riello Burner
2106 East Indiana Ave., Bismarck, ND 58504 U.S.A. • www.macheaters.com • +1-800-272-4604
GB
2453
14
SPARE PARTS LIST
No. CODE DESCRIPTION No. CODE DESCRIPTION
1 3020510 BURNER BACK COVER
2 3007077 CRUSHABLE METAL WASHER
3 3005771 BANJO CORE ADAPTER - PRESSURE PORT
4 3005803 BANJO FITTING - PRESSURE PORT
5 3005804 BANJO CORE ADAPTER - RETURN LINE
6 3007079 CRUSHABLE METAL WASHER
7 3005805 BANJO FITTING - RETURN
8 3007028 O-RING - PUMP PRESSURE REGULATOR
9 3007202 REGULATOR SCREW
10 3007162 O-RING - PUMP COVER
11 3005719 PUMP SCREEN
12 3006925 VALVE STEM
13 3007203 VALVE STEM PLATE
14 3005847 1/4” NPT/ METRIC ADAPTER - FEMALE
15 3006571 3/8” NPT/METRIC ADAPTER - MALE
16 3007029 O-RING - VALVE STEM UPPER
17 3007156 O-RING - VALVE STEM LOWER
18 3006995 PIPE CONNECTOR - RETURN
19 3007893 BLEEDER
20 3006553 COIL U-BRACKET AND KNURLED NUT
21 3002279 COIL
22 3007806 PUMP
23 3006994 PIPE CONNECTOR - SUPPLY
24 3000443 PUMP DRIVE KEY
25 3005845 MOTOR
26 3005858 UNION - NOZZLE TUBE / EXTENSION
27 3007318 AIR TUBE COVER
28 3006500 HI FIRE DELAY VALVE
29 3020487 PRIMARY CONTROL 530SE/C 24V
30 3002280 PHOTO-CELL
31 3002278 PRIMARY CONTROL SUB BASE
32 3005809 OIL PRESSURE TUBE
33 3005808 OIL RETURN TUBE
34 3005849 SEMI FLANGE
35 3005851 UNIVERSAL MOUNTING FLANGE
36 3005852 MOUNTING GASKET
37 3006499 HYDRAULIC JACK
38 3008050 CAPILLARY TUBE
39 3000645 HYDRAULIC AIR SHUTTER
40 3007211 AIR INTAKE HOUSING
41 3005799 FAN
42 3005857 NOZZLE OIL TUBE EXTENSION
43 3005846 CAPACITOR 16 µF
44 3007358 ACOUSTIC LINER
45 3005801 GASKET
OPTIONAL
46 3002762 DUCTED COMBUSTION AIR INTAKE KIT
50 3949271 SHORT COMBUSTION HEAD 5” (275T1)
51 3005897 TURBULATOR DISC
52 3005896 CROSS - CASTING
53 3006965 NOZZLE ADAPTER
54 3006987 NOZZLE OIL TUBE - SHORT
55 3005900 REGULATOR ASSEMBLY - SHORT
56 3005902 ELECTRODE ASSEMBLY - SHORT
57 3005869 ELECTRODE PORCELAIN
58 3005894 END CONE
59 3005892 SHORT AIR TUBE
50 3949272 LONG COMBUSTION HEAD 10” (275T2)
51 3005897 TURBULATOR DISC
52 3005896 CROSS - CASTING
53 3006965 NOZZLE ADAPTER
54 3006988 NOZZLE OIL TUBE - LONG
55 3005901 REGULATOR ASSEMBLY - LONG
56 3005903 ELECTRODE ASSEMBLY - LONG
57 3005869 ELECTRODE PORCELAIN
58 3005894 END CONE
59 3005893 LONG AIR TUBE
