MAC 6000 Hydronic Heater
Trailer Axle Manual
2106 East Indiana Ave., Bismarck, ND 58504 U.S.A. • www.macheaters.com • +1-800-272-4604
32
Rev: 07.25.2013
12" Brakes and Kits
12" BRAKES AND KITS
Callout Description Part #
A Brake, Electric - LH x 12" x 2" 122259
B Brake, Electric - RH x 12" x 2" 122451
C Brake, Electric - LH x 12" x 2" Self Adjust 1222593
D Brake, Electric - RH x 12" x 2" Self Adjust 1224513
E Brake, Hyd Uni-Servo - LH x 12" x 2" 138754
F Brake, Hyd Uni-Servo - RH x 12" x 2" 138755
G Brake, Hyd Free-Backing - LH x 12" x 2" 139419
H Brake, Hyd Free-Backing - RH x 12" x 2" 139420
I Brake Lock Nut ⁄" - 24 122077
Electric Brake Kits
12" x 2" Shoe & Lining Kit, 1 Brake (includes front
and rear shoe)
136444
12" Magnet Kit (Includes Magnet, Magnet Srping,
and clip)
136447
12" Spring & Hardware Kit (Includes hold-down
pins, hold-down springs, and retractor springs)
136445
Adjuster Screw and Spring Kit (includes Adjuster
and Adjuster Spring)
136453
A - H
I
