Before you start
Getting started...
GB
IE
Assembly
Set the product on a suitable at >
surface.
Turn the tension wheel (8) until >
the chain “tie straps” are just
touching the bottom edge of the
guide bar (4) (Fig. 8).
8
4
7
Fig. 8
Check the chain tension using one hand to lift the saw chain >
(3) against the weight of the product. The correct chain tension
is achieved when the saw chain can be lifted by approximately
2 - 4 mm from the guide bar (4) in the centre (Fig. 9, 10).
2-4 mm
Fig. 9 Fig. 10
Turn the locking wheel (7) to >
tighten the cover (9) completely
(Fig. 11).
7
a
b
Fig. 11
