Hardware Basics
Precaution:
Please make sure your hand is dry and remove static from your body by touching metal parts of
your computer chassis.
6
--- Back Panel
--- 2 -6mm Screws
--- 6 -5mm Screws --- 8 -4mm Screws--- Base Tray bridge
--- Front Panel
--- Base Tray
--- Power button
--- Enclosure Sleeve
Security Slot
USB Data
Cable Connector
DC Jack
eSATA Data
Cable Connector
Back Panel
