4. (a) Seat the Circuit Board and hard drive to the Bottom Tray. (b) Secure
the hard drive with Screws (5mm in diameter) on the bottom of the tray.
5. Align the Bottom Tray to the Sleeve Slot. Slide and push the hard drive/
Bottom Tray into the Enclosure Sleeve.
6. Put the Back Panel back to the Enclosure.
hard drive & circuit board
Bottom Tray
10
(a)
(b)
