P0010/082016/Rev.0.0 77
For a thorough cleaning, the spout head can be disassembled as shown.
6 – Drip tray
The drip tray catches excess liquid which can be easily removed by pulling
out the tray. The drip tray also serves to collect coffee grounds.
Note: ensure that when the coffee tray is inserted back into
the coffee machine, the coffee grounds container is also
reinserted.
