P0010/082016/Rev.0.0 79
9 – Brewing unit
The brewing unit has a cover and is located behind the water tank. It can
easily be detached, cleaned and put back in again.
1. Remove the Water tank
2. Flap the lower cover under the tank to the right.
3. Squeeze the two red buttons together and keep them pressed
4. Remove the cover
Now you can see that the Brewing unit is fixed with a lever.
5. Move the lever to the „open“-Symbol and pull out the Brewing
unit.
After cleaning it you can place it again and lock it with the lever.
The Brewing unit is calibrating itself after closing the cover.
