10
Fig. 2-4
WATER/CYCLE DRAIN FOR MAINS RINSE
2.5 litri 2.5 - 3 litri 2.5 - 3 litri 3 - 4 litri
minimum
very good for
glass-washers
good for
dish-washers
very good for
dish-washers
Fig. 2-5
• Connect the drain hose of the appliance to the outlet (D), fitting a siphon between the
hose and the outlet. Alternatively, place the appliance over a drainage well (E), which
should be fitted with a cover (F) to prevent the build-up of unpleasant odours.
2.3 WATER DRAIN
