A-21
PARTS
055-113-00 REV B continued
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
212-031-00 CAPACITOR CERAMIC SMT 68pF 5% C57-58 C61-62 C157-158 C161-162
C257-258 C261-262 C357-358 C361-362
C457-458 C461-462 C557-558 C561-562
C657-658 C661-662 C757-758 C761-762
C857-858 C861-862 C957-958 C961-962
C1057-1058 C1061-1062 C1157-1158
C1161-1162
220-002-02 CAPACITOR LYTIC RADIAL TAPE 47UF 10% C25-26 C67 C69 C167 C169 C267 C269
C367 C369 C467 C469 C567 C569 C667
C669 C767 C769 C867 C869 C967 C969
C1067 C1069 C1167 C1169
220-008-02 CAPACITOR LYTIC RADIAL TAPE 1UF 10% C9-10 C53-54 C83-84 C109-110 C153-154
C209-210 C253-254 C309-310 C353-354
C409-410 C453-454 C509-510 C553-554
C609-610 C653-654 C709-710 C753-754
C809-810 C853-854 C909-910 C953-954
C1009-1010 C1053-1054 C1109-1110
C1153-1154
220-027-02 CAPACITOR LYTIC RADIAL TAPE 10UF 10% C1-2 C15-16 C81-82 C89-90 C101-102
C115-116 C201-202 C215-216 C301-302
C315-316 C401-402 C415-416 C501-502
C515-516 C601-602 C615-616 C701-702
C715-716 C801-802 C815-816 C901-902
C915-916 C1001-1002 C1015-1016
C1101-1102 C1115-1116
320-012-00 IC LINEAR SMD NJM4560M U1-2 U6-7 U51 U101-102 U151 U201-202
U251 U301-302 U351 U401-402 U451
U501-502 U551 U601-602 U651 U701-702
U751 U801-802 U851 U901-902 U951
U1001-1002 U1051 U1101-1102 U1151
325-053-03 IC, SMD, SCH TRIGGER HEX INV. 74AC14 U5
329-045-03 D/A CONV SM CS4390 U52 U152 U252 U352 U452 U552 U652
U752 U852 U952 U1052 U1152
329-046-03 A/D CONV SM CS5360 U3-4 U103 U203 U303 U403 U503 U603
U703 U803 U903 U1003 U1103
400-147-00 CONNECTOR STR LCK SHRD 26P .100 X 2 J12
400-152-00 CONNECTOR STR LCK SHRD 34P .100 X 2 J13
400-183-00 CONN HDR 26P .100 X 2 RTA SHRD J1-3
400-184-00 CONN HDR 40P .100 X 2 RTA SHRD J11
400-192-00 CONN HDR 20P .100 X 2 RTA SHRD J15
450-113-00 PCB, CODEC CARD Z9
601-009-00 FERRITE BEAD, SMT Z=1000 FB1-4 FB12-15 FB18-27 FB101-104
FB201-204 FB301-304 FB401-408
FB501-508 FB601-608 FB701-708
FB801-808 FB901-908 FB1001-1008
FB1101-1108
601-010-00 FERRITE BEAD, SMT Z=73 FB9-11 FB16-17
601-014-00 INDUCTOR 4.7UH 1206 SMT 4.7uH L1-16
706-055-00 STANDOFF, SWAGE, 6-32 X .500L Z1-8
