A-22
PARTS
055-114-00 REV C, DSP CARD
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
E1-2
140-025-00 RESISTOR TF SMT 10 5% R3 R5 R9 R12 R27-32 R34 R43-58 R67
R95-96 R101-102 R137 R172 R213 R248
R255-274 R334-337 R368 R403 R438 R473
R508 R543 R613 R648 R683 R718 R753
R788 R823 R858 R893 R896-903 R906-913
R916-923 R926-933 R936-943
140-042-00 RESISTOR TF SMT 51 5% R59 R64-65 R68-69 R78-93 R99-100
R103-104 R113-128 R134-135 R138-139
R148-159
140-049-00 RESISTOR TF SMT 100 5% R61-63 R94 R97-98 R129-130 R132-133
R167-168 R208-209 R243-244 R254
R303-304 R327-328 R363-364 R398-399
R433-434 R468-469 R503-504 R538-539
R573-574 R608-609 R643-644 R678-679
R713-714 R748-749 R783-784 R818-819
R853-854 R888-889
140-065-00 RESISTOR TF SMT 470 5% R13-14 R20
140-073-00 RESISTOR TF SMT 1K0 5% R21 R33
140-097-00 RESISTOR TF SMT 10K 5% R1-2 R4 R6-8 R10-11 R15-19 R22-26 R35-39
R70-74 R105-109 R140-144 R160 R175-179
R216-220 R251-252 R338-340 R371-375
R406-410 R441-445 R476-480 R511-515
R546-550 R581-585 R616-620 R651-655
R686-690 R721-725 R756-760 R791-795
R826-830 R861-865
140-123-00 RESISTOR TF SMT 100K 5% R40-42 R60 R66 R75-77 R110-112 R131
R136 R145-147 R180-188 R221-223
R341-343 R376-378 R411-413 R446-448
R481-483 R516-518 R551-553 R586-588
R621-623 R656-658 R691-693 R726-728
R761-763 R796-798 R831-833 R866-868
145-000-00 RESISTOR SMT 0 5% R253
212-016-00 CAPACITOR CERAMIC SMT 1000PF 5% C251
212-027-00 CAPACITOR CERAMIC SMT .1UF 10% C1-250 C252
223-003-00 CAPACITOR LYTIC SMT 22UF 20% C257-270
301-001-00 DIODE POWER 1N4002 D4
304-064-03 LED, SMT, 0805 RED D1
304-065-03 LED, SMT, 0805 GRN D2
304-066-03 LED, SMT, 0805 YEL D3
315-004-00 OSCILLATOR 7.3728 MHZ Y1
315-012-00 OSC SMT 22.5792MHZ 22.5792 MHZ Y2
324-004-03 HIGH SPEED CMOS RS-232 ADM232A U48
DRIVERS/RECEIVERS
325-035-03 IC, SMD, HEX INVERTER 74AC04 U110
325-037-03 IC, SMD, DCDR/DEMUX 74AC138 U28-29 U40-42
325-038-03 IC, QUAD, OR, SMD 74AC32 U49 U53 U55 U59 U62 U65 U68 U71 U74
U77 U80 U83
325-039-03 IC, SMD, DUAL D F/F 74AC74 U107
325-042-03 IC, SMD, OCTAL D-TYPE FF 74AC574 U26 U30-35 U39 U44 U47 U50-51 U54
U56-58 U60-61 U63-64 U66-67 U69-70
U72-73 U75-76 U78-79 U81-82 U84-85
U87-88 U90-91 U93-94 U96-97 U99-100
U102-103 U105-106 U108-109 U111-112
U114-115 U117
