A-23
PARTS
055-114-00 REV C continued
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
325-043-03 OCTAL 3-STATE NONINVERTING 74AC241A U46 U86 U89 U92 U95 U98
BUFFER
325-053-03 IC, SMD, SCH TRIGGER HEX INV. 74AC14 U27 U43 U52 U101 U104
325-054-03 IC, SMD, OCTAL, D-TYP, TRANS 74AC573 U36
LATCH
335-001-00 IC, SMD, DIGITAL SIGNAL U1-24
PROPRIETARY PROCESSOR
335-002-00 IC, SMD, DIGITAL SIGNAL ADSP-2181 U25
PROCESSOR
335-003-00 IC, SMD, U/P SUPERVISORY ADM705 U37
CIRCUIT
335-004-00 IC, SMD, ASYNCHRONOUS TL16C452 U45
COMMUNICATIONS
400-057-00 CONNECTOR STR 14P .100 X 1 J1
400-077-00 HEADER STR LCK SHRD 20P .100 X 2 J21
400-078-00 CONNECTOR STR LCK SHRD 10P .100 X 2 J25
400-147-00 CONNECTOR STR LCK SHRD 26P .100 X 2 J12
400-152-00 CONNECTOR STR LCK SHRD 34P .100 X 2 J13 J24 J47-48
400-219-00 CONNECTOR STR 5P .156 X 1 J42
LOCKING KEYED
401-001-32 IC SOCKET, 32 PIN, DIP U38
450-114-00 PCB, DIGITAL 8-BUS: DSP CARD Z1
601-010-00 FERRITE BEAD, SMT Z=73 FB1-4
