Mackie d8b v3 - Page 52

A-24
PARTS
055-115-00 REV E, DIGITAL I/O
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
080-066-00 PIC PRGMD 115PCB D8 U3
140-025-00 RESISTOR TF SMT 10 5% R34
140-049-00 RESISTOR TF SMT 100 5% R15 R24 R33 R35-37
140-073-00 RESISTOR TF SMT 1K0 5% R1 R3 R5-9 R11-14 R18 R21-22
140-097-00 RESISTOR TF SMT 10K 5% R2 R4 R27-29
140-110-00 RESISTOR TF SMT 33K 5% R10
145-162-00 RES MF SM .1W 1% 47R5 OHM 47R5 1% R16-17
145-193-00 RES MF SM .1W 1% 100 OHM 100 1% R19-20 R23 R30-32 R40-43 R50
145-289-00 RES MF SM .1W 1% 1K00 OHM 1K00 1% R38-39
200-011-02 PLY .0022UF 10% 100V TR 0.0022 2.50% C23
200-019-02 CAPACITOR MYLAR TAPE 0.1 10% C7-8 C10-11
212-001-00 CAPACITOR CERAMIC SMT 0.01 10% C20 C24 C27
212-004-00 CER 220PF 5% 50V NPO SM 220PF 5% C22 C25-26 C28-30 C32-40
212-007-00 CAPACITOR CERAMIC SMT 0.047 5% C14
212-015-00 CAPACITOR CERAMIC SMT 33PF 5% C3-4
212-025-00 CAP CER .1UF 50V 10% X7R .1UF 10% C1-2 C5-6 C9 C12-13 C15-19 C21 C31
C44 C50
212-032-00 CER 2200PF 10% 50V X7R 2200PF 10% C41
311-005-00 X-SISTOR NPN SMD IMBTA06 Q1
315-010-00 OSCILLATOR 16 MHZ X3
315-015-00 CRYSTAL, SMD 20MHZ X1
325-012-03 IC, SMD, 8 BIT SHIFT REGISTER 74HC595 U1-2
W/ OUTPUT LATCHES
325-027-03 CMOS 74HC74A DUAL D FLPFL 74HC74A U7
325-033-03 IC, SMD, EIA RS-485 ADM1485 U4-6 U15
TRANSCEIVER
329-021-03 TRANSMITTER CS8402A CS8402A U13
329-022-03 RECEIVER CS8412 CS8412 U19
329-023-03 IC, CONVERTER, SMT AD1890 U12
400-131-00 CON XLR PC MTG HORIZ FML SML NC3FAH1O J2
400-175-00 CONN XLR 3PIN MALE RTA, A-SERIES J3
400-213-00 CON, RCA DUAL PCMT J6
450-115-00 PCB,D8 BUS, DIGITAL I/O Z1
601-009-00 FERRITE SMT SIG 1K OHM Z=1000 5% FB3-8
601-010-00 FERRITE BEAD, SMT Z=73 FB1-2
601-016-02 EMI T FILTER 1000PF 1000PF L3-8
712-020-00 BRKT ANG 6-32X.037THK STL Z8
