A-25
PARTS
055-119-00 REV B, TAPE I/O
PART NO. DESCRIPTION VALUE REFERENCE DESIGNATORS
J1 J2
080-067-00 PIC PRGMD 119PCB D8 PIC16C54S U4
140-009-00 RESISTOR TF SMT 2.2 5% R10 R56 R110 R156 R210 R256 R310 R356
140-049-00 RESISTOR TF SMT 100 5% R11-13 R15-16 R35-42 R52 R54-55 R58
R111-113 R115 R152 R154-155 R158
R211-213 R215 R252 R254-255 R258
R311-313 R315 R352 R354-355 R358
140-051-00 RESISTOR TF SMT 120 5% R70 R73 R170 R173 R270 R273 R370 R373
140-073-00 RESISTOR TF SMT 1K0 5% R99 R103-104 R106-109
140-097-00 RESISTOR TF SMT 10K 5% R14 R31 R100 R114 R116 R119-123 R214
R314
140-110-00 RESISTOR TF SMT 33K 5% R105
140-123-00 RESISTOR TF SMT 100K 5% R27-30
141-051-00 RESISTOR TF SMT 120 5% R71-72 R171-172 R271-272 R371-372
145-000-00 RESISTOR SMT 0 5% R32-34
145-210-00 RESISTOR MF SMT 150 1% R83-98
145-318-00 RESISTOR MF SMT 2K00 1% R3 R6-7 R19-20 R23-24 R43-44 R47-48 R53
R63 R78-79 R82
145-338-00 RESISTOR MF SMT 2K94 1% R51 R59 R64 R66 R151 R159 R164 R166
R251 R259 R264 R266 R351 R359 R364
R366
145-388-00 RESISTOR MF SMT 9K76 1% R57 R60 R65 R67 R157 R160 R165 R167
R257 R260 R265 R267 R357 R360 R365
R367
145-389-00 RESISTOR MF SMT 10K0 1% R1-2 R4-5 R8-9 R17-18 R21-22 R25-26
R45-46 R49-50 R74 R76 R80-81 R101-102
R117-118 R201-202 R217-218 R301-302
R317-318
145-389-00 RES MF SM .1W 1% 10K0 1% R132-139 R124-131
145-454-00 RESISTOR MF SMT 47K5 1% R61-62 R68-69 R161-162 R168-169
R261-262 R268-269 R361-362 R368-369
145-485-00 RESISTOR MF SMT 100K 1% R75 R77 R175 R177 R275 R277 R375 R377
212-003-00 CAPACITOR CERAMIC SMT 100PF 5% C3-4 C13 C17-21 C26-38 C103-104 C113
C117-118 C203-204 C213 C217-218
C303-304 C313 C317-318
212-012-00 CAP, CER, SMD, NPO/COG 2200PF 5% C14 C22 C114 C122 C214 C222 C314
C322
212-015-00 CAPACITOR CERAMIC SMT 33PF 5% C5-6
212-016-00 CAPACITOR CERAMIC SMT 1000PF 5% C59-60 C63-64 C159-160 C163-164
C259-260 C263-264 C359-360 C363-364
212-025-00 CAP CERAMIC SMT X7R .1UF 10% C7-8 C11-12 C23-25 C51-52 C55-56
C111-112 C123-124 C151-152 C155-156
C211-212 C223-224 C251-252 C255-256
C311-312 C323-324 C351-352
212-031-00 CAP CERAMIC SMT 68pF 5% C57-58 C61-62 C157-158 C161-162
C257-258 C261-262 C357-358 C361-362
220-002-02 CAP LYTIC RADIAL TAPE 47UF 10% C67 C69 C167 C169 C267 C269 C367
C369 C373-374
220-008-02 CAP LYTIC RADIAL TAPE 1UF 10% C9-10 C53-54 C109-110 C153-154
C209-210 C253-254 C309-310 C353-354
220-027-02 CAP LYTIC RADIAL TAPE 10UF 10% C1-2 C15-16 C101-102 C115-116
C201-202 C215-216 C301-302 C315-316
311-005-00 X-SISTOR NPN SMD IMBTA06 Q1
315-015-00 CRYSTAL, SMD 20MHZ Y1
320-012-00 I.C. LINEAR SMD NJM4560M U1-2 U51 U101-102 U151 U201-202 U251
U301-302 U351
To Next Page
