Mackie d8b v3 - Page 75

A-47
PARTS
080-036-00 Rev A1 Linear supply subassembly
PART NO. DESCRIPTION REV QTY
040-284-00 DIS 18GA BRN/BLU .156 7.5 E 1
040-285-00 DIS 26GA 2C 2MM/.100 6.5 A 1
055-123-00-01 PCB ASSY LINEAR SPLY - D8 E3 E1 1 see chapter 123, Mackie linear P/S
080-110-00 SA TWISTED PAIR LINEAR SP A 1
410-002-00 INSL SILPAD .007 SELF ADH A 2
480-027-00 SW PWR SPLY ASTEC 5V 22A A 1 OEM switching P/S
550-198-00 HTSK BRKT PWR DIST-40.8 A 1
550-401-00 FAB BRKT HTSNK ASTEC D8PW A 1
550-418-00 FAB BRKT HTSK LINEAR SPLY A 1
700-028-00 SEMS 6-32X1/4 PHP BLKZC B 7
700-028-03 SEMS 6-32X1/2 PHP BLKZC B 2
700-086-00 TF 6-32X3/8 FL 100DG BLK A 2
730-026-00 ADHESIVE RTV162 A AR
080-107-00 Rev A1 Power transformer subassembly
PART NO. DESCRIPTION REV QTY
400-084-00 7P .156X1 22GA END C 1
400-210-00 TERM QDISC .250 F 18-22GA A 2
600-036-00 XFMR POWER D8 120V B 1
080-108-00 Rev A1 Power Switch subassembly
PART NO. DESCRIPTION REV QTY
040-248-00 DIS 18GA 1010 BLU 14 QDX2 B 1
040-286-00 DIS 18GA 1010 BLK 14 QDX2 A 1
040-287-00 DIS 18GA 1010 WHT 14 QDX2 A 1
040-288-00 DIS 18GA 1010 BRN 14 QDX2 A 1
500-040-00 SW DPST PWR RCKR W/LED A 1
740-001-00 TYRAP 3-1/4L A 2
740-011-00 HEATSHRINK TUBE 2:1 .50ID B 10
080-109-00 Rev B2 Hard/Floppy drive subassembly
PART NO. DESCRIPTION REV QTY
080-090-10 SA FORMATTED HD VER2.01 A1 A2 1
480-029-00 OEM FLOPPY DRV 3.5 BLACK B 1
550-361-00 BRKT DISK DRV D8 PWR SPLY A 2
700-028-00 SEMS 6-32X1/4 PHP BLKZC B 4
700-085-03 SCR PHP M3X6 STL BLK ZC A 4
