A-48
PARTS
090-123-00 DIGITAL 8 BUS CONSOLE CE REV A3
PART NO. DESCRIPTION REV QTY
090-123-00 DIGITAL 8 CONSOLE CE A A3 1
040-138-00 CBL 3P 22GA .098CL 17IN A 1
040-141-00 RIB 28GA 26C 8IN PLZD A 5
040-142-00 RIB 28GA 40C 8IN PLZD A 4
040-143-00 RIB 28GA 25C 4.5IN DSUB B 1
040-145-00 RIB 28GA 26C 2.5IN PLZD A 1
040-146-00 RIB 28GA 34C 3IN PLZD A 1
040-147-00 RIB 28GA 20C 11.5IN PLZD A 1
040-149-00 RIB 28GA 34C 10.5IN PLZD A 1
040-195-00 RIB 28GA 10C 23IN PLZD A 1
040-196-00 RIB 28GA 34C 21IN PLZD A 1
040-197-00 RIB 28GA 26C 6IN PLZD A 2
040-198-00 RIB 28GA 34C 8.25IN PLZD A 1
040-199-00 RIB 28GA 34C 11.5IN PLZD A 1
040-200-00 RIB 28GA 34C 18IN PLZD A 1
040-202-00 RIB 28GA 26C 20.5IN PLZD B 1
040-203-00 RIB 28GA 34C 4IN PLZD A 1
040-204-00 RIB 28GA 34C 6.5IN PLZD A 1
040-211-00 RIB 28GA 26C 13.5IN PLZD A 1
040-212-00 RIB 28GA 20C 8.5IN PLZD A 2
040-213-00 RIB 28GA 20C 17.5IN PLZD A 1
040-252-00 RIB 28GA 20C 22 28IN DSUB A 1
040-253-00 RIB 18GA 7C .156X1 6.75IN A 1
040-254-00 RIB 18GA 8P .156X1 19IN A 1
040-255-00 RIB 18GA 5C .156X1 21.5IN A 1
040-277-00 RIB 28GA 40C 1IN PLZD A 1
040-278-00 DIS 16GA 1007 GN/YL 5 Q/L B 1
040-300-00 CBL DATA 25P EMI FRT D8 A 1
040-340-00 DIS 14GA BLK 6.5 LUG/LUG A 1
055-108-00 PCB ASSY MIC/LINE METERS 52 A1 1
055-109-00 PCB ASSY LINE/MSTR METER 55 A1 1
055-110-00-01 PCB ASSY ANA I/O JACKFLD B6 B1 1
055-111-00 PCB ASSY PWR DIST - D8 B1 B1 1
055-112-00-01 PCB ASSY DCA - D8 C C1 1
055-113-00-01 PCB ASSY CODEC - D8 B B1 1
055-114-00-01 PCB ASSY DSP - D8 C2 C1 1
055-115-00-03 PCB ASSY DIGITAL I/O - D8 E E3 1
055-120-01 PCB ASSY MIC/CNTRL SURF A1 A1 1
055-121-01 PCB ASSY LINE/CTL SURF D8 A1 A1 1
055-122-01 PCB ASSY OUT/CTL SURF -D8 A1 A1 1
055-124-00 PCB ASSY FADER X 8 - D8 31 A1 2
055-125-00 PCB ASSY FADER X 9 - D8 31 A1 1
055-136-00-01 PCB ASSY CNTRL BRAIN - D8 A7 A1 1
055-154-00 PCB IVL EFFECTS D8 A A1 1
055-163-00-01 PCB ASSY EFFECTS BACKPLN C1 C1 1
055-164-00-01 PCB ASSY CLOCK - D8 C C1 1
055-191-00 PCB ASSY JOG WHEEL D8 1 A1 1
080-096-00 SA VFD D8 A A1 1
091-136-00 CONSOLE WARNING SHEET D8 B 1
400-406-00 ADAPTER MIDI BRKOUT CABLE A 1
550-260-00 SCREEN TOP PANEL D8 B 1
550-261-00 PNT FRONT MTR BRIDGE D8 A 1
550-262-00 PAINT BOTTOM - D8 A 1
550-263-00 FAB SIDE PANEL LEFT D8 A 1
550-264-00 FAB SIDE PANEL RIGHT D8 A 1
Latest Parts List July 2001
