DL1608
Digital Live Sound Mixer
with iPad
®
Control
DL1608 SPECIFICATIONS CONTINUED...
DSP
Input Channel Processing [1-16]: HPF, EQ, Comp, Gate
Output Channel Processing [LR, A1-A6]: GEQ, Comp/Limiter
FX: Reverb, Delay
Power
Power Consumption: 48 watts max
External Supply
Power Requirements: 100 VAC – 240 VAC,
50 – 60 Hz
Universal Supply
Output Voltage: 12 VDC
Current: 4A
DC Connector: 5.5 mm x 2.5 mm barrel with locking ring
Line Cord: User-replaceable IEC
Operating Temperature 0 - 40 ˚C
[extended ambient temperature]: 32 - 104 ˚F
Physical Properties (packaged product)
Height: 6.1 in / 155 mm
Depth: 18.9 in / 480 mm
Width: 18.1 in / 460 mm
Weight: 12.8 lb / 5.8 kg
Physical Properties (product)
Height (Front): 1.6 in / 40 mm
Height (Rear): 3.7 in / 95 mm
Depth: 15.4 in / 391 mm
Width: 11.5 in / 291 mm
Weight: 7.9 lb / 3.6 kg
Rack: Nine Rack Spaces [Needs an additional
space or two above to allow for connections]
Options
DL1608 Rackmount Kit: P/N 2036840
DL1608 Mixer Bag: P/N 2036809-16
DL1608 Mixer Cover: P/N 2036809-17
Ordering Information
DL1608 Digital Live Sound Mixer with iPad Control, US: P/N 2037372-00
DL1608 Digital Live Sound Mixer with iPad Control, EU: P/N 2037372-01
