DL1608
Digital Live Sound Mixer
with iPad
®
Control
DL1608 SPECIFICATIONS
General Digital
Sample Rate: 48 kHz
A/D/A Bit Depth: 24-bit
System Latency: 1.5 ms
Frequency Response
All inputs to all outputs: ±0, –1 dB, 20 Hz to 20 kHz
Distortion (THD)
Mic input to main output, 1 kHz, –1 dBFS: <0.005%
Noise / Dynamic Range / Signal-to-Noise Ratio
Equivalent Input Noise (EIN)
150 termination: –128 dBu
Mic input to main output (A-weighted)
Channel and main faders at unity: –79 dBu
Faders down: –90 dBu
Crosstalk
Adjacent inputs: <–120 dB @ 1 kHz
Outputs: <–105 dB @ 1 kHz
Phones level pot feedthrough @ minimum travel: <–75 dB
Signal-to-Noise Ratio
(ref +4 dBu, one channel and main fader at unity,
A-weighted): 92 dB
Dynamic Range
(One channel and main fader at unity, A-weighted): 109 dB
CMRR: >70 dB @ 1 kHz (60 dB gain)
Analog Inputs 1-16
Connectors
1-12: XLR Balanced
13-16: Combo XLR / TRS Balanced
XLR Mic Pre: Onyx
Input Impedance
1-12: 3 k
13-16: 3 k mic [XLR]
30 k
line [1/4"]
Max Input Level
XLR: +21 dBu
1/4": +30 dBu
Gain
XLR: 0 to 60 dB
1/4": –20 to 40 dB
48V Phantom Power (XLR): 48 VDC, 10 mA max per mic,
with up to eight simultaneously.
5 mA max per mic,
with up to 16 simultaneously.
Analog Main Out L/R
Connectors: XLR Balanced
Output Impedance: 600
Max Output Level: +21 dBu
Analog Aux Sends 1-6
Connectors: 1/4" TRS Impedance Balanced
(Supports balanced / unbalanced operation)
Output Impedance: 240
Balanced
120 Unbalanced
Max Output Level: +21 dBu
Analog Headphone Out
Connector: 1/4” TRS Stereo
Max Output Level: +18 dBu into 600
+19.5 dBu max into 100
Networking
Connector: 100 MB Ethernet
Control: Complete
Simultaneous Control: 10 iPad Devices
iPad Support
iOS Version Requirement: 5.1 or greater
iPad Version Requirement
Wired: Original iPad, iPad 2,
iPad (3rd generation)
Wireless: Original iPad, iPad 2,
iPad (3rd generation),
iPad (4th generation),
iPad mini
Control Application: Mackie Master Fader App
1
1
https://itunes.apple.com/us/app/mackie-master-fader/id511500747?mt=8
