Appendix B: Technical Info
Onyx FireWire Card Specications
Mic In to FireWire Card to DAW, routed back to FireWire Card to Control
Room Output; all signal path gain stages set to unity
Frequency Response
+0, –3 dB, 10 Hz to 42 kHz @ 96 kHz sample rate
+0, –1 dB, 10 Hz to 20 kHz @ 44.1 kHz sample rate
Distortion (THD+N)
< 0.025%, 10 Hz to 40 kHz, +4 dBu input @ 96 kHz sample rate
< 0.015%, 20 Hz to 20 kHz, +4 dBu input @ 96 kHz sample rate
< 0.010%, 20 Hz to 20 kHz, +4 dBu input @ 44.1 kHz sample rate
Dynamic Range
> 98 dB, 20 Hz to 20 kHz @ 96 kHz sample rate
> 100 dB, 20 Hz to 20 kHz @ 44.1 kHz sample rate
Main Mix Trim
+10 dB to –10 dB, unity detent
Dimensions
Height: 1.3 in/32 mm
Width: 8.8 in/222 mm
Depth: 3.6 in/91 mm
Weight: 8.3 oz./235 g
LOUD Technologies Inc. is always striving to improve our products by
incorporating new and improved materials, components, and manufacturing
methods. Therefore, we reserve the right to change these specications at
any time without notice.
