3-Way Active Speaker System
FUSSION 3000
SPEAKER
FUSSION 3000
oF 6 PAGES
2
OF 8 PAGES
Specifi cations
System Acoustic
Frequency Range (–10dB): 45Hz–20kHz
Frequency Response (–3dB): 55Hz–18kHz
Horizontal Coverage Angle (–6dB): 80˚ averaged
2kHz to 10kHz
Vertical Coverage Angle (–6dB): 70˚ averaged
2kHz to 10kHz
Directivity Factor; DI(Q): 10.19 (10.46) averaged
2kHz to 10kHz
Rated Maximum SPL (long term): 130dB @ 1m
Rated Maximum SPL (peak): 133dB @ 1m
Rated Maximum SPL-High Pass On: 85Hz–18kHz: 132dB
(long term)
Rated Maximum SPL-High Pass On: 85Hz–18kHz: 135dB
(peak)
Crossover Points: 500Hz, 2,500Hz
Dynamic Range: >110dB
Phase Response: ±35˚ from 500Hz to 10kHz
Transducers
Low Frequency (4 each wired series-parallel)
Cone Diameter: 12” (300mm)
Voice Coil Diameter: 3” (75mm)
Power Handling: 350 watts rms (long term)
1
Mid Frequency
Cone Diameter: 8” (200mm)
Voice Coil Diameter: 2” (50mm)
Power Handling:
150 watts rms (long term)
1
High Frequency
Diaphragm Diameter: 3” (75mm)
Throat Exit Diameter: 1.4” (35.6mm)
Diaphram Material: Titanium
Power Handling: 75 watts rms (long term)
1
Amplifi ers
Low Frequency:
Rated Output per AES standard @ low frequency
driver impendance:
1000 watts Continuous Average Power
1500 watts peak
Type: Class G High Effi ciency, High Current
Cooling: Convection Extrusion
Mid Frequency:
Rated Output per AES standard @ mid frequency
driver impendance:
200 watts Continuous Average Power
300 watts peak
Type: Mosfet Based Class AB
Cooling: Convection Extrusion
High Frequency:
Rated Output per AES standard @ high frequency
driver impendance:
100 watts Continuous Average Power
150 watts peak
Type: Mosfet Based Class AB
Cooling: Convection Extrusion
Audio Input / Output / Controls
Main Input, Loop Out: 50kΩ impedance, balanced
Sub-Out Signal: 85Hz low pass output with
protection and active monitoring
for FUSSION 1800S/1800SA
active subwoofer system
Fill Out Signal: 85Hz high-pass signal
Fill Out Signal Level Control: 0 dB to –30 dB
Fill Out Phase Control: 0˚–180˚
High-Pass Switch: Allows system to
operate from 85Hz up only
Line Input Power
US: 120VAC, 60Hz
Recommended Amperage Service: 20A
AC Connector: 3 pin Twistlock 250VAC, 20A male
Europe: 230VAC, 50Hz
Recommended Amperage Service: 16A
AC Connector: 3 pin IEC 250VAC, 16A male
In-rush Current Protection: Yes, transistor based
Control System Functions
Electronic Crossover
Phase Alignment
Time Correction
Equalization
Safety Features
RMS Limiting: Monitoring and limiting of
continuous RMS output of amplifi ers
Thermal: Monitoring of thermal condition of
power supply and amplifi ers. High
temperature condition engages input
stage shut down and auto reset function.
Physical
Enclosure: Trapezoidal, 15° side angles,
18mm multi-layered birch
Hanging Inserts: 4 points on top
Rigging Inserts: 2 points, 1 each side ATM MEGS
1 pull back clip, bottom
Handles: 4 ea. aluminum/rubber grips
Color: Black, splatter paint
Grille: Custom perforated oval steel grille
with anti-corrosive treatment
Dimensions:
Height: 41 in (104.1cm)
Front Width: 25 in (63.5cm)
Rear Width: 13.9 in (35.3cm)
Depth: 23 in (58.4cm)
Net Weight: 246 lbs. (112kg)
Options
Active Subwoofer System: Fussion 1800SA / 1800S
Flyware: ATM Megs Compatible
Footnote 1: Power handling for transducers is based on AES long term power testing standard
conducted for 100 hours full power, free air.
