Mackie PA152 - PA152 Specifications; System Specifications; Transducer Specifications; Physical Specifications

Two-Way Speaker System
PA152
SPEAKER
PA152
oF 6 PA GE S
2
O F 6 P A G E S
Specications
oF 6 PA GE S
3
O F 6 P A G E S
Two-Way Speaker System
PA152
oF 6 PA GE S
4
O F 6 P A G E S
oF 6 PA GE S
2
O F 6 P A G E S
System
Freq. Range (–10 dB): 50 Hz–21 kHz
Freq. Response (–3 dB): 70 Hz–20 kHz
Horz. Coverage Angle (–6 dB): 85° averaged
1 kHz to 16 kHz
Vert. Coverage Angle (–6 dB): 65° averaged
1 kHz to 16 kHz
Directivity Factor; Q (DI): 11 (10.5) averaged
1 kHz to 16 kHz
System Sensitivity
1
: 97 dB, 1 W @ 1 m
Rated Maximum SPL: 130 dB, @ 1 m
System Nominal Impedance: 8 Ω
System Input Power Rating
2
: 500 W RMS; 2000 W Peak
Recommended Amplier
3
: 750 W
HF Protection: Dynamic
Crossover: 1.6 kHz, 12 dB/Octave
Transducers
Low-Frequency: 15" (380 mm) woofer with
4" (100 mm) coil
Nominal Impedance: 8 Ω
Input Power Rating: 350 W AES; 1400 W Peak
Sensitivity
1
: 97 dB, 1 W @ 1 m
High-Frequency: 2" (51 mm) throat,
3" (76 mm) coil titanium
compression driver assembly
Nominal Impedance: 16 Ω
Input Power Rating: 75 W AES; 300 W Peak
Sensitivity
1
: 107 dB, 1 W @ 1 m
Physical
Enclosure: Trapezoidal, 15° back angles,
19 mm multilayered birch
Rigging Inserts: 12 points; accepts M10
threaded hardware,
3 eyebolts provided
Color: Black, scratch resistant paint
Grille: Custom perforated steel grille
with open-cell poly ber backing
Input Connectors: Speakon
®
NL4
Dimensions (HxWxD): 29.85" x 19.90" x 18"
(758 mm x 505 mm x 455 mm)
Net Weight: 96.8lb. (44 kg)
Options
PA-A1 Forged shoulder M10 eyebolt hardware
1 Measured on axis in the far eld with 1 watt (2.83 V RMS, 8 Ω or 4.0 V RMS, 16 ohms) input and
referenced to 1 meter distance using the inverse square law. Listed sound pressure represents an
average from 300 Hz to 3 kHz.
2 RMS using 20 Hz to 20 kHz, PN Spectrum, Peak for 2 hours with +6 dB crest factor.
3 Recommended Amplier is a power capability value that should be taken as a guide.
