Mackie SRM350v3 User Manual

4/9 PAGES
SRM350v3
SRM450v3
1000W High-Definition
Powered Loudspeakers
NOTES:
1. SYMBOL INDICATES CENTER OF BALANCE.
2. WEIGHT APPROX. 23.0 lb [10.4 kg].
3. SHIPPING WEIGHT APPROX. 29 lb [13.2 kg].
FRONT SIDE TOP
THE INFORMATION CONTAINED
HEREIN IS PROPRIETARY AND
CONFIDENTIAL PROPERTY OF
LOUD TECHNOLOGIES, INC.
ALL RIGHTS RESERVED
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE IN INCHES
DUAL [MM] DIMENSIONS
FOR REF ONLY
TOLERANCE IN INCHES
LINEAR ± 0.13 in / ± 3.3 mm
ANGLES ± 1°
(X.XX) = REF DIMS
NO TOLERANCE IMPLIED
TSC = THEORETICAL SHARP CORNER
DIMENSIONS ACROSS CENTERLINES
TO BE SYMMETRICAL
THIRD ANGLE PROJECTION
10.6
[270]
12.3
[311]
13.1
[333]
5.7
[146]
7.0
[179]
20.8
[527]
SRM350v3 LOUDSPEAKER DIMENSIONS

Mackie SRM350v3 Specifications

General

Product color	Black
Recommended usage	Universal
Suitable for outdoor use	-
Woofer	Yes
Magnet type	Ferrite
Speaker type	2-way
Number of drivers	2
Speaker placement	Tabletop/bookshelf
Audio output channels	2.0 channels
Number of woofer drivers	1
Woofer diameter (imperial)	10 \
Impedance	8 Ω
Sensitivity	126 dB
Frequency range	55 - 20000 Hz
RMS rated power	500 W
Crossover frequency	3000 Hz
Peak Music Power Output (PMPO)	1000 W
Connectivity technology	Wired
Current	10 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	160 W
Operating temperature (T-T)	0 - 40 °C
Package depth	335 mm
Package width	386 mm
Package height	635 mm
Package weight	13200 g

Weight and Dimensions

Depth	311 mm
Width	333 mm
Height	527 mm
Weight	10400 g
