999051 – Revision B Page | 25 of 40
7.2 Specifications
Front and Rear Casters Size
Moving force (with 180 kg)
Carry bar rotation (180kg)
7.3 Electrical Specifications
Battery type: 2 x 12-volt Rechargeable sealed lead acid.
Battery capacity: 24 V DC, 1 x 2.9 Ah
Charger rated input: 230VAC 50/60Hz
Charger rated output: 27.4/29.0 VDC @ 0.8A
Electric Shock Protection
Charger: Class II *Lift - internal power source
Degree of shock protection: Type B *Lift - internal power source
Duty cycle: 10% Use – 90% Rest (90 seconds use - 810 seconds rest)
IP rating, control box: IPX4
IP rating, battery: IPX5
IP rating, handset: IPX4
Expected Product Lifetime
10 yrs. depending usage and compliance to maintenance, servicing and LOLER inspections.
7.4 Standards Applied
The standards that have been applied to the device are as follows:
• EN 10535:2006 Hoists for the transfer of disabled persons. Requirement and test methods
