Madas EVP/NC - Coils and Connectors Overview

Bobine e connettori - Coils and connectors
Bobines et connecteurs - Bobinas y conectores
Attacchi
Connections
Voltaggio
Voltage
Codice bobina completa
di connettore
Coil code
complete with
connector
Timbratura
bobina
Coil
stamping
Codice solo
connettore
Connector
code only
Tipo connettore
Connector type
DN 32 - DN 40 - DN 50
(P.max 360 mbar)
12 Vdc BO-1000 12 Vdc DN 32 - 40 - 50 CN-2000
NORMALE
NORMAL
24 Vdc BO-1010 24 Vdc DN 32 - 40 - 50 CN-2000
NORMALE
NORMAL
24 V/50 Hz BO-1015 24 Vac DN 32 - 40 - 50 CN-2010
RADDRIZZATORE + Energy Saving
RECTIFIER + Energy Saving
110 V/50-60 Hz BO-1020 110 Vac DN 32 - 40 - 50 CN-2020
RADDRIZZATORE + Energy Saving
RECTIFIER + Energy Saving
230 V/50-60 Hz BO-1030 230 Vac DN 32 - 40 - 50 CN-2030
RADDRIZZATORE + Energy Saving
RECTIFIER + Energy Saving
DN 65 ÷ DN 80
(P.max 360 mbar)
24 Vdc BO-1110 24 Vdc DN 65 - 80 CN-2000
NORMALE
NORMAL
24 V/50 Hz BO-1115 24 Vac DN 65 - 80 CN-2010
RADDRIZZATORE + Energy Saving
RECTIFIER + Energy Saving
110 V/50-60 Hz BO-1120 110 Vac DN 65 - 80 CN-2020
RADDRIZZATORE + Energy Saving
RECTIFIER + Energy Saving
230 V/50-60 Hz BO-1130 230 Vac DN 65 - 80 CN-2030
RADDRIZZATORE + Energy Saving
RECTIFIER + Energy Saving
DN 100 ÷ DN 150
(P.max 360 mbar)
24 Vdc BO-1210 24 Vdc DN 100 CN-2000
NORMALE
NORMAL
24 V/50 Hz BO-1215 24 Vac DN 100 CN-2010
RADDRIZZATORE + Energy Saving
RECTIFIER + Energy Saving
110 V/50-60 Hz BO-1220 110 Vac DN 100 CN-2020
RADDRIZZATORE + Energy Saving
RECTIFIER + Energy Saving
230 V/50-60 Hz BO-1230 230 Vac DN 100 CN-2030
RADDRIZZATORE + Energy Saving
RECTIFIER + Energy Saving
Per le bobine e connettori di ricambio dei modelli Q - R - S - T - contattare il ns uffi c i o t e c n i c o .
For coils and connectors of Q - R - S - T models as spares, please contact our technical department.
