Specifications
The correlation between published specifications and performance is unreliable. A
list of numbers reveals virtually nothing. All technical measurements must be sub-
ject to qualitative as well as quantitative interpretation.
Measurements of the DAP yield excellent results by any standards. However, only
those specifications that apply to its actual operation are included here.
■ Frequency response: 10 Hz – 20 kHz, +0dB, –0.2dB
■ Total harmonic distortion: 0.005% @ 1 kHz, A-weighted
■ Maximum output: 2 V rms (0 dB output)
■ Dynamic range: 98 dB (or better)
■ Signal to noise ratio (balanced outputs): 105 dB (ref: 0 dB output)
■ Channel separation: better than 110 dB
■ Analog filter: Bessel-tuned, linear phase to 40 kHz
■ Low-level linearity: deviation unmeasurable to below -70 dB
approximately +1.7 dB below -90 dB
(undithered, referenced to 0 dB @ 1 kHz)
■ Volume range: -116 dB to 0 dB
■ Volume resolution: 0.55 dB steps above 43 in display,
gradually increasing step size at lower levels
■ Digital inputs: 1 each AES/EBU, BNC, RCA, EIAJ, ST
■ Digital input impedance: 110Ω (AES/EBU electrical)
75Ω (S/PDIF electrical)
■ Digital outputs: 1 RCA (S/PDIF)
■ Digital output impedance:75Ω (S/PDIF electrical)
■ Audio outputs: 1 set balanced stereo outputs
1 set single-ended stereo outputs
■ Other input:1
1
⁄8" mini-jack for external IR repeater
■ Power consumption: less than 40 W
■ Mains voltage: determined by the needs of country for which
the unit was manufactured; cannot be reset by dealer or user
■ Output impedance: less than 20Ω
■ Overall dimensions: See “Dimensions”
■ Shipping weight: 25 lbs. (12.4 kg)
For more information, see your Proceed dealer, or contact:
Madrigal Audio Laboratories, Inc.
P.O. Box 781, 2081 South Main Street
Middletown, Connecticut 06457 USA
Telephone (860) 346-0896 FAX (860) 346-1540
If purchased in the United States or Canada, the warranty on this Proceed product
is owner-transferable. If your product requires service, you must obtain a Return Au-
thorization before shipping it to Madrigal. Madrigal reserves the right to repack any
product which arrives improperly packed for shipment and to charge the owner for
the required packing material.
For warranty information and conditions on products purchased in other countries,
contact your local dealer or distributor.
