Mag-lite C CELL - Page 9

C & D Flashlight
ML Rev.1 8/03
9
421-000-391
STEP 10
Using the HEX WRENCH (22) center the
SWITCH (15) and Tighten the SET SCREW
(21).
STEP 12
Replace the HEAD ASSEMBLY (1).
STEP 11
Replace the LAMP (10).
STEP 9
Push the SWITCH ASSEMBLY (15) into the
BARREL (13) until it stops at the SNAP RING
(14).
