Seat Assembly Instructions
Step 1:
Remove seat from packaging and identify the seat
bottom (E1) and seat back (E2)
The seat back (E2) clamps onto seat bottom (E1)
via plastic clamps on ends of seat back (see
circles below)
Step 2:
Inspect the sides of the seat bottom frame and
notice the holes on either side (see circles below for
location reference)
Align clamps on seat back (E2) with the holes in the
seat bottom (E1) frame, the clamps have a round
detent that will fit into the holes on the seat frame
ensuring proper alignment. Press the two sides of
the clamp firmly together until you hear them snap
together.
Page 12 of 29
Seat Bottom
Seat Back
Seat Bottom
Seat Back
