Page 4
Specifications
Hardware Compatibility
Power input voltage: 12Vdc
Frequency: 433MHz or 868MHz
Sensitivity: -120 dBm
Current consumption: 50 mA
Dimensions
(no antenna):
15cm x 16cm x 3cm (6in x 6.5in x 1.1in)
Operating temperature: 0°C to 49°C (32°F to 120°F)
PGM outputs: PGM1 and PGM2 - 150mA PGM transistor
outputs
PGM3 - form C relay output rated at 5A/28Vdc,
N.O./N.C. (PGM4 optional)
Range: Refer to the appropriate transmitter Instructions
Other: Di-pole antenna; Error Correction Algorithm
Approvals: For the latest information on product approvals,
visit our Web site at paradox.com
