Magellan RTX3 - LED Feedback; Programming; Programming for Imperial

Page 8 Programming
LED Feedback
Chapter 3: Programming
This chapter provides programming instructions for Imperial, Spectra SP
Series, EVO, Esprit, and stand alone installations.
Programming for Imperial
When connected to an Imperial panel, all RTX3 settings are programmed using
BabyWare. For more detailed instructions on using BabyWare and
programming remotes, refer to the Imperial System Guide.
All Panels
ERROR
Problem with the module
BUS RX
Receiving from panel
BUS TX
Transmitting to panel
RF RX
Receiving wireless
RF TX
Transmitting wireless
R
G
G
G
Y
EVO and SP Series only
ERROR
BUS RX
BUS TX
Com fail: GRN/YEL
short / no data
R
ERROR
BUS RX
BUS TX
Com fail: too many
modules / wrong data
R
G
ERROR
BUS RX
BUS TX
Com fail: GRN/
YEL reversed
G
R
G
ERROR
BUS RX
BUS TX
Combus power
too low
R
Legend
R = Red
G = Green
Y = Yellow
= Off
= On
= Flashing
