6
SERVICE ACCESS (4)
REAR COVER
(A)
(B)
(C)
(F)
Rear cover
(D)
(E)
TO REMOVE
1. Remove the face cover and front cover (see pages 4 to 5).
2. Loosen the setscrews (A), (B), and (C), and remove setscrews (D), (E), and (F).
3. Pull up the spool pins. Remove the machine socket. Remove the rear cover clearing
the presser foot lifter from the slit on the cover.
TO ATTACH
4. Follow the above procedure in reverse.
