Changing The Reversible Doo
CAUTION: To avoid personal injury to yourself
and/or property, we recommend someone
assist you during the door reversal process.
1. Remove the top hinge assembly and keep them for
later use.
2. Remove the bottom hinge assembly and keep them
for later use.
3. Remove the plug buttons from the upper left holes
and transfer them to the uncovered holes at the
right side. Be sure to press the plug buttons
firmly into the holes.
4. Re-install the top hinge assembly previously
removed in step 1 on the opposite side.
5. Re-install the bottom hinge assembly previously
removed in step 2 on the opposite side.
6. Re-install the door assembly with the door handle
on the opposite side (Rotating the door assembly
for 180°) .
7. Make sure the door assembly is properly aligned on
the cabinet before tightening the screws.
The process is now complete.
Note: If desired, change the door swing before installation.
