CHANGING THE REVERSIBLE DOOR
CAUTION: To avoid personal injury to yourself and/or property, we recommend someone
assist you during the door reversal process.
Your refrigerator is built with a reversible door. You have the choice of either opening it from the left
or the right side. In order to reserve the opening direction of your door, please follow these simple
instructions:
1. Remove the hinge cover on the right top of the
cabinet.
2. Remove the two screws (using a ratchet tool
with a 7/16” socket) that hold the top hinge to
the cabinet. Keep these screws for later use.
3. Lift the top hinge straight up to free the pin
from the socket on the top of the door.
4. Lift the door and place it on a padded surface
to prevent scratching it.
5. Remove the plug buttons from the upper left
holes as illustrated and transfer them to the
uncovered holes at the right side. Be sure to
press the plug buttons firmly into the holes.
7
