Magnum XL .52RFS User Manual

Revision 2 September 2009
Replacement parts can be ordered directly from your local Magnum engine hobby retailer. If your hobby retailer does not stock Magnum engines, you can order replacement parts direct from us. Global Services 18480 Bandilier Circle, Fountain Valley, CA 92708  Email: service@globalhobby.net
XL .52RFS AIRCRAFT ENGINE EXPLODED PARTS VIEW
284070
281510
281174
281160
284265 281160 284085 284267
284068
281507
281022
282004
284065
280109
280812
282408
281308
281307
281601
280611
281210
280416
281418
280709
280933 280935 280934
281117
282002
280520
281417
280313
280210
281308
284092
284071
284069
281403
281403
284067 284067
284066 284066
284086 282450 282450
284063
282450
282309
282231
282202
282109
284064 282407
282606
282002
281903
284206
281901
281166
282450
281803
281804
Carburetor Assembly (Complete)
280010
282501
282004
282501
282004
282501
284062
  
280010 52801 Carburetor Assembly - Complete 280109 52601 Mufer Assembly - Complete 280210 52228 Propeller Nut, Safety Nut, and Washer 280313 52-A Drive Washer with Woodruff Key 280416 52210 Crankshaft 280520 52101X Crankcase 280611 52102 Backplate 280709 52204 Connecting Rod 280812 52213 Wrist Pin with Retainer 280933 52231 Piston 280934 52232 Sleeve 280935 52236 Piston Ring 281022 52-N Cylinder Head with Valves 281117 52112F Cylinder Head Gasket Set 281160 80841 Lock Washers (2) (M3) 281166 12862 Needle Valve Seat Assembly 281174 80719 Rocker Arm Retaining Bolt (M3 x 16mm) 281210 52111 Backplate Gasket 281307 52134 Carburetor Retaining Bolts (M2.5 x 20mm) 281308 12518 Intake Pipe / Camshaft Cover Bolts (M2.5 x 8mm) 281403 12109 Camshaft Ball Bearing 281417 52109 Front Ball Bearing 281418 52110 Rear Ball Bearing 281507 160120 Cylinder Head Bolts (M3 x 18mm) 281510 12122 Valve Cover Bolts (M2.5 x 12mm) 281601 40134 Backplate Bolts (M3 x 8mm) 281803 12861 High Speed Needle Valve with O-Ring 281804 12860 High Speed Needle Valve Assembly - Complete 281901 12833 Needle Valve Detent Spring 281903 12847 Needle Valve Seat Gasket 282002 12819 Fuel Nipple with Fiber Washer 282004 12114 Fuel Nipple 282109 52-B Rotor Bolt 282202 12812 Throttle Arm 282231 12811 Throttle Arm Retaining Nut 282309 52-C Low Speed Needle Valve with O-Ring 282407 52816 Carburetor O-Ring 282408 52831 Intake Pipe Gasket 282450 12845 O-Ring for Needle Valves and Pushrod Tubes 282501 91137 Fiber Washer for Fuel Nipple 282606 52-D Idle Stop Screw with Spring 284062 52218 Woodruff Key 284063 52-E Pushrod Set 284064 52-F Intake Pipe 284065 52-G Exhaust Pipe with Cinch Nuts (2) 284066 52-H Intake Valve Set 284067 52-J Exhaust Valve Set 284068 52-K Rocker Arm Assembly - Complete 284069 52714 Camshaft 284070 FS52711 Valve Cover (Blue) 284071 52-M Camshaft Housing Cover with Bolts 284085 80517 Rocker Arm Retaining Clip 284086 52729 Camshaft Followers (2) 284092 52732 Camshaft Cover Gasket 284206 12830 Needle Valve Seat 284265 12118 Rocker Arm Lifter Nut (M3) 284267 80724 Rocker Arm Lifter Bolt
