Magnum XLS .52A User Manual

280110 46609 Mufer Gasket 280201 40228 Propeller Nut and Washer 280713 S52204 Connecting Rod 281151 400160 Sleeve Index Pin 281154 S91225 Drive Washer Spacer 281155 S91109 Ball Bearing - Front 281159 40120 Cylinder Head Mounting Bolts (6) 281160 80841 Lock Washers (2) 281163 91130 Lock Washer 281166 12862 High Speed Needle Valve Seat - Complete 281168 46871F Rear Needle Valve Mount Plug 281240 S40119 Carburetor Retaining Bolts (2) 281242 S40219 Drive Washer 281244 S40873F Rear Needle Valve Mount Only 281245 S40813 Throttle Barrel 281246 S40901 Bolt Set - Cylinder Head and Backplate 281265 S40863 Carburetor Body with Spray Bar 281306 28123 Rear Needle Valve Mounting Bolts (2) 281420 40110 Ball Bearing - Rear 281601 40134 Backplate Mounting Bolts (4) 281715 120616 Mufer Axial Bolt with Nut 281720 S40120 Mufer Mounting Bolts (2) 281798 S15860 High Speed Needle Valve Assembly - Complete 281799 S15861 High Speed Needle Valve with O-Ring 281800 S40874F Rear Needle Valve Assembly - Complete 281901 12833 High Speed Needle Valve Detent Spring 281903 12847 Needle Valve Seat/Plug Gasket 282002 12819 Fuel Nipple with Gasket 282004 12114 Fuel Nipple without Gasket 282130 46814A Throttle Barrel Spring
282159 S32868F Carburetor Plug 282201 46866 Throttle Arm 282310 46810F Low Speed Needle Valve with O-Ring 282401 40816 Carburetor Base O-Ring 282412 40845 Low Speed Needle Valve O-Ring 282452 46845F High Speed Needle Valve O-Ring 282501 91137 Fiber Washer 282608 46837F Idle Stop Screw with Nut 283022 S40801F Carburetor Assembly - Complete 283023 S40803F Carburetor and Rear Needle Valve Assemblies 284206 12830 High Speed Needle Valve Seat 284220 S52103X Cylinder Head 284221 S52112 Cylinder Head Gaskets (2) 284222 S52203 Piston and Sleeve Set 284223 S52213 Wrist Pin and Retainer Set 284225 S52101 Crankcase 284226 S52210 Crankshaft 284227 S52111 Backplate Gasket 284228 S52102 Backplate 284229 S52601X Mufer - Complete 284230 S52604X Mufer Middle 284231 S52416 Gasket Set - Cylinder Head and Backplate
ORDER # REFERENCE # DESCRIPTION
Revision 3 August 2009
Replacement parts can be ordered directly from your local Magnum engine hobby retailer. If your hobby retailer does not stock Magnum engines, you can order replacement parts direct from us. Global Services 18480 Bandilier Circle, Fountain Valley, CA 92708 Phone: (714) 963-0329 / Fax: (714) 964-6236 Email: service@globalhobby.net
XLS .52A AIRCRAFT ENGINE EXPLODED PARTS VIEW
284220
284221
284222
284223
280713
281720
281160
281240
281240
284225
281155
281154
281242
280201
281420
281151
284226
284227
284228
281800
281306
281601
281160
281715
281715
281163
284230
282004
284229
280110
284231
281246
282201
282310
282412
281245
282401
282130
282608
281265
282002
281903
282159
283022
283023
281168
282501
281244
284206
281901
282452
281799
281798
281166
281800
282002
281903
281160
281160
281159
