The following is the LTM-250/350 LCD Menu Flowchart
Magtech Magtech
LTM-250 or LTM-350
SW Rev
1.00.00
HW Rev
1.00.00
Display?
Scroll > Level > Intrface* > Temp** > mA Out > % Range
SelLngth
30.00 in
Lvl Unit
in > ft > mm > cm > m
Temp Unit**
C > F > R > K
Sel PV*
Level > Interface
Sel Alrm
FailHigh > FailLow > HoldOut
ChgRnge? >>> Sel LRV >>> Sel URV
Yes > No (yes) 0.00 in 24.00 in
SelDamp
1 sec
ROC Fltr
10.0in/s
TrmSnsr? >>> TrimZero >>> TrimZero >>> TrimSpan >>> TrimSpan >>> Span
Yes > No (yes) -Busy- 24.00in -Busy- Error (if incorrect)
Offset
0.00in
TrimDAC? >>> Trim 4mA >>> Trim20mA
Yes > No (yes) 120 3860
TstLoop? >>> LoopTest
Yes > No (yes) 4.00 mA
Exit?
Yes > No
* Only applies when Interface Float is included
** Only applies when Temperature Sensor is included
