4. Place the inner tyre bead over the rim
5. Place the outer tyre bead over the rim
6. Inflate all tyres to the prescribed pressure, check the valve area for leakage
and re-balance the wheels prior to installing back on the vehicle
Starting to mount the tyre from the valve location is a wrong fitment. The fixing
tool/stem may hit the sensor and damage it. Start from the opposite direction.
12.6.4 TPMS Sensor Removal
1. Remove the tyre from the rim
2. To remove the sensor, firstly remove the screw using a T10 TORX screwdriver
3. Carefully and firmly pull the enclosure straight back off the valve
