C-79
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Operation :
PERIOD 1 (1 HOUR) :
Operate the engine with no load and with the
throttle at 3/4 position.
PERIOD 2 (2 HOURS) :
Operate the engine with light load and with the
throttle at 3/4 position.
PERIOD 3 (1 HOUR) :
Operate the engine with medium load and with
the fuel rack at full position.
NOTE:
COOLING SYSTEM PROTECTION
Operate the engine with light load and with the
fuel rack at 3/4 position.
% Anti Freeze / % Water 50/50 60/40
Freeze Protection -34
0
F -64
0
F
Boil over protection +265
0
F +275
0
F
(with 15 psi radiator cap)
Recommended change period : 1 year or when
ever the radiator water is drained.
1. SPECIFICATIONS
Capacity - US Gallon 2.24 (4DI), 1.84 (3DI)
Pump - Type Centrifugal
- Direction of rotation viewed from front Clockwise
Fan Belt - Type Single V
- Slack between pulleys 3/8 - 1/2"
Thermostat - Opening temperature 82
O
C (180
O
F)
Cooling System
