C-90
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Air Cleaner
For Air cleaner Servicing Proceed as follows:
6. Open the hood.
7. Check the dust unloader valve (E) and clean if
necessary.
8. Turn the clamp (F) of air cleaner.
9. And remove cover (G).
10. Remove Primary Element (H).
Remove Secondary Element
(Inner Element) ONLY if it is to be replaced. DO NOT
attempt to clean Secondary Element.
If Secondary Element is replaced, install new element
immediately to prevent dust from entering air intake
system.
11. Replace Secondary Element (J), if dirty or
damaged.
Dust Unloader
Cyclopack
Primary Element Filter
Safety Cartridge
J
To Next Page
